Dehumidifier

Description

DY-HD series honeycomb dehumidifiers are mainly used to dry and dehumidify hygroscopic engineering plastics. Our dehumidifier adopts imported well-known brand honeycomb rotor, which has a super effective drying and dehumidifier. We offer accurate P.I.D temperature control as standard, with LCD touch screen and dew-point monitor as optional features. DY-HD series includes 14 models for option, the largest of which can provide dry air up to a volume of 4000m3/hr.

Models: DY-DH80

1. Dingyuan's honeycomb dehumidifier are equipped with imported well-known brand honeycomb rotor for dehumidifying, it has long service life. They have two kinds of design: Fully-integral and semi-integral depending on the size.
2. It is the molecular sieve structure honeycomb, which provides low dew-point dry air(-40℃ or even lower). Also it can achieve constant detection of all the parameters and stabilize the dew-point. The largest of which can provide dry air up to a quantity of 4,000m³/hr.
3. P.I.D. temperature controller to accurately can accurately control the drying temperature, temperature controlling accuracy of ±1℃ (Optional PLC with LCD touch man-machine interface selected for more convenient on operation and monitoring)
4. The main pipe of the dehumidifier is made of stainless steel
5. Efficient cold exhaust design with a cooler to ensure a low return air temperature and low dew-point, that makes the machine operation more stable
6. Imported famous brand high-quality spare parts and domestic industry leading parts to ensure better performance for the dehumidifier.
7. Clean the door design for easy cleaning
8. 7 days timer function
9. Inbuilt return air filter avoids honeycomb contamination and ensures long service life.
10. Reasonable pipeline design makes it has high dehumidifying and drying efficiency
11. Full-function alarm system that can immediately respond to error.

Model Unit DY-DH80
Drying blower power KW 0.75
Regen-blower power KW 0.2
Regen-heater power KW 3.8
The pipe inlet & outlet Inch 2
Voltage V 220V/380V/415V//440V/3Phase
Size MM 600*680*1300
Dia.Cooling water Inch 3/4"
Total power KG 215
Net Weight KW 4.8
  • Plastic Granule
  • Granule
